Home / Products / Toolboxes / Bearing Pressure
  • TB-MAP user interface
    TB-MAP user interface

Bearing Pressure

TB-MAP

The TB-MAP module can be used to verify the load capacity of the bearing pressure depending on the load position and the selected masonry.

to the shop
Input options Design Output options Standards

Discover now more programs from the section Toolboxes Masonry!

SHOW MORE
Material

according to standard, user-defined as well as according to approval:

  • Wienerberger
  • Schlagmann Poroton
  • UNIPOR
  • Kellerer ZMK Ziegelsysteme
  • BV Leichtbeton
Calculations
  • Verification of the permissible load
  • Determination of the height and width of the required concrete cushion if the load capacity is exceeded
Documents
  • PDF
  • Word
  • Printer
Output

Standard output

Standards
  • DIN EN 1996

Support resources

Manual
Manual
